Building the Perfect Spotify Now Playing Widget in SvelteKit

You've likely encountered one of those cards or widgets displaying the most recent or current song you're listening to. In this guide, I'll take you through the process step by step on how to build it. We'll start by creating the app on Spotify, generating the necessary tokens, and then proceed to implement the server-side API calls on SvelteKit. Additionally, we'll cover the creation of the related frontend component that will utilize these API calls.

Creating Spotify App

To create the app on Spotify you can follow the following official tutorial

Be sure to do the following things

Add the following address to the Redirect URIs
- http://localhost:3000
Copy and save
- Client ID
- Client Secret

Storing sensitive key in an .env file

It's always a good practice to store keys for API calls or other sensitive information within an .env file, which you'll almost certainly add to the .gitignore to prevent any accidental leakage of data.

Create and .env file in the root of the project and add to it your CLIENT_ID and CLIENT_SECRET.

Be sure to do the following things

Remember to prefix the variable name with
VITE_ otherwise they will not be exposed to the client, as you can read on the documentation

Text

VITE_SPOTIFY_CLIENT_ID=<clientid>
VITE_SPOTIFY_CLIENT_SECRET=<clientsecret>

Spotify Authorization Code Flow

As you can see here, in order to gain access to the Spotify API, a very specific authorization flow must be followed.

The basic steps are as follows.

Authorization Request to obtain the code
Use this access code to get the refresh token
Use the refresh token to get the access token
Use the access token to obtain API data

Requesting User Authorization

To get the authorization code, we have to make a GET request to https://accounts.spotify.com/authorize using the following parameters:

client_id: that we have saved before
response_type: must be set to code
redirect_uri: http://localhost:3000 (or another address that you set in the Redirect URIs)
scope: are used to determine which resources you have permissions to access (you can find the full list here), and for our purpose we will use these:
- user-read-currently-playing
- user-top-read
- user-read-recently-played

Since this step only needs to be done once, we'll simply compose the address as follows and enter it into a browser window.

Text

https://accounts.spotify.com/authorize?client_id=<clientid>&response_type=code&redirect_uri=http%3A%2F%2Flocalhost:3000&scope=user-read-currently-playing%20user-top-read%20user-read-recently-played

Once executed it should redirect to a url similar to this one.

Text

http://localhost:3000/?code=code

Get the code and saved because we will need it to get the refresh token.

Getting a Refresh Token

Now the fastest way to get the refresh token is to make a POST request to the correct endpoint. You can use any software you want to do this but the fastest is cURL.

Bash

curl -H "Authorization: Basic <base64 encoded client_id:client_secret>" -d grant_type=authorization_code -d code=code -d redirect_uri=http%3A%2F%2Flocalhost:3000 https://accounts.spotify.com/api/token

Here we need to enter:

The code we saved earlier
A Base64 encoded string given by the format clientid:clientsecret
- It can be created here

Once the address has been created and executed, simply copy and save in the .env file the refresh token.

Text

VITE_SPOTIFY_CLIENT_ID=<clientid>
VITE_SPOTIFY_CLIENT_SECRET=<clientsecret>
VITE_SPOTIFY_REFRESH_TOKEN=<refreshtoken>

Getting an Access Token

The advantage is that the refresh token never expires, allowing us to use it as many times as needed to obtain a new access token, which itself has a one-hour expiration time.

Now let's create our endpoint src > routes > api > spotify > accesstoken > +server.ts

TypeScript

const client_id = import.meta.env.VITE_SPOTIFY_CLIENT_ID;
const client_secret = import.meta.env.VITE_SPOTIFY_CLIENT_SECRET;
const refresh_token = import.meta.env.VITE_SPOTIFY_REFRESH_TOKEN;

const redirect_uri = 'http://localhost:5173/';
const token_endpoint = `https://accounts.spotify.com/api/token`;

const cacheToken = {
	expires_in: 0,
	access_token: ''
};

export async function GET() {
	// Check if the token is expired and refresh it if necessary
	if (cacheToken.expires_in < Date.now()) {
		// Refresh the token
		const tokenResponse: unknown = await fetch(token_endpoint, {
			method: 'POST',
			headers: {
				'Content-Type': 'application/x-www-form-urlencoded'
			},
			body: new URLSearchParams({
				grant_type: 'refresh_token',
				refresh_token,
				redirect_uri,
				client_id,
				client_secret
			})
		}).then((res) => res.json());

		// Handle invalid token response
		if (!isTokensPayload(tokenResponse)) {
			return new Response(JSON.stringify({ error: 'Invalid token' }));
		}

		// Update the cache with the new token and expiration time
		cacheToken.access_token = tokenResponse.access_token;
		cacheToken.expires_in = Date.now() + tokenResponse.expires_in * 1000;
	}
	return new Response(
		JSON.stringify({ access_token: cacheToken.access_token })
	);
}

Use the obtained access token to request to Spotify API

Now that we have our access token, we can use it to make the API call to Spotify, and we can use it to get the now playing/last played song or top tracks from the user's account.

Now Playing / Last Played Endpoint

Now let's create our endpoint src > routes > api > spotify > nowplaying > +server.ts

TypeScript

const now_playing_endpoint =
	'https://api.spotify.com/v1/me/player/currently-playing';
const recently_played_endpoint =
	'https://api.spotify.com/v1/me/player/recently-played';

const cacheSong = {
	track: {},
	status: 'offline',
	expires_in: 0
};

export async function GET() {
	// Get the access token
	const { access_token } = await get('/api/spotify/accesstoken');

	// Check if the song cache is expired
	if (cacheSong.expires_in < Date.now()) {
		// Retrieve the current playing song
		const currentPlayingResponse = await fetch(now_playing_endpoint, {
			headers: {
				Authorization: `Bearer ${access_token}`
			}
		});

		// Process response for the current playing song
		if (currentPlayingResponse.status === 200) {
			const currentPlaying = await currentPlayingResponse.json();

			// Update the cache with the current playing song
			cacheSong = {
				track: currentPlaying.item,
				status: curretPlaying.is_playing ? 'online' : 'offline',
				expires_in:
					Date.now() +
					(curretPlaying.is_playing ? 5 * 60 * 1000 : 2 * 60 * 1000)
			};

			return new Response(
				JSON.stringify({
					track: currentPlaying.item,
					status: curretPlaying.is_playing ? 'online' : 'offline'
				})
			);
		}

		// If no current playing song, get the last played song
		const recentlyPlayedResponse = await fetch(recently_played_endpoint, {
			headers: {
				Authorization: `Bearer ${access_token}`
			}
		});

		// Process response for the last played song
		if (recentlyPlayedResponse.status === 200) {
			const recentlyPlayed = await recentlyPlayedResponse.json();

			// Update the cache with the last played song
			cacheSong = {
				track: recentlyPlayed.items[0].track,
				status: 'offline',
				expires_in: Date.now() + 2 * 60 * 1000
			};

			return new Response(
				JSON.stringify({
					track: recentlyPlayed.items[0].track,
					status: 'offline'
				})
			);
		} else {
			return new Response(
				JSON.stringify({
					track: cacheSong.track,
					status: cacheSong.status
				})
			);
		}
	}
}

Top Tracks Endpoint

Now let's create our endpoint src > routes > api > spotify > toptracks > +server.ts

TypeScript

// toptracks/+server.ts
const top_tracks_endpoint = 'https://api.spotify.com/v1/me/top/tracks';

export async function GET() {
	// Get the access token
	const { access_token } = await get('/api/spotify/accesstoken');

	// Retrieve the top tracks
	const topTracksResponse = await fetch(top_tracks_endpoint, {
		headers: {
			Authorization: `Bearer ${access_token}`
		}
	});

	// Process response for the top tracks
	if (topTracksResponse.status === 200) {
		const topTracks = await topTracksResponse.json();

		return new Response(
			JSON.stringify({
				top_tracks: topTracks.items
			})
		);
	}

	return new Response(
		JSON.stringify({
			top_tracks: []
		})
	);
}

Creating Spotify Component

Now that we have all the necessary endpoints, we can create our component. First, let's create a new file src > components > spotify > NowPlaying.svelte. This will be the component that will display the current playing song or the last played song.

svelte

<script lang="ts">
  async function getRecentlyPlayed() {
    const response = await fetch("/api/spotify/recentlyplayed");
    const data = await response.json();
    return data;
  }
</script>

<div class="wrapper">
  {#await getRecentlyPlayed()} // Add loading skeleton here {:then data}
  <a
    class="song"
    href="{data.track.external_urls.spotify}"
    target="_blank"
    rel="noreferrer"
  >
    <div class="logo">// Add spotify logo here</div>
    <div class="info">
      <span class="label">
        {#if data.status === 'online'}
        <div>
          <span class="label">
            <span class="bar bar1"></span>
            <span class="bar bar2"></span>
            <span class="bar bar3"></span>
          </span>
          Now playing
        </div>
        {:else} Offline. Last played {/if}
      </span>
      <div class="scrolling-title">
        <div class="title">
          <span>{data.track.name}</span>
          <span>{data.track.name}</span>
          <span>{data.track.name}</span>
          <span>{data.track.name}</span>
          <span>{data.track.name}</span>
        </div>
      </div>
      <p class="description">{data.track.artists[0].name}</p>
    </div>
    <div class="album">
      <img
        src="{data.track.album.images[0].url}"
        alt="{data.track.album.name}"
        width="640"
        height="640"
      />
    </div>
  </a>
  {:catch}
  <div class="wrapper">
    <div class="error">
      <div ="logo">// Add spotify error logo here</div>
      <p>Something went wrong load Spotify data!</p>
    </div>
  </div>
  {/await}
</div>

<style lang="scss">
  .wrapper {
    display: flex;
    justify-content: flex-start;
    align-items: center;
    width: 100%;
    padding: 2rem;
    background-color: #212329;
    background-position: center center;
    background-size: cover;
    border-radius: 2rem;
    position: relative;
    min-height: 10rem;
    overflow: hidden;

    .error {
      display: flex;
      justify-content: center;
      align-items: center;
      flex-direction: column;
      gap: 2rem;

      .logo {
        width: 50px;
        height: 50px;
      }

      p {
        font-size: 1.3rem;
        text-align: center;
      }
    }

    .song {
      display: flex;
      justify-content: flex-start;
      align-items: center;

      .logo {
        width: 35px;
        height: 35px;
        margin-right: 20px;
      }

      .info {
        position: relative;
        z-index: 2;

        .label {
          color: #59cbc0;
          display: flex;
          justify-content: flex-start;
          align-items: center;
          gap: 0.5rem;
          font-size: 1.2rem;

          .barWrapper {
            margin-right: 1rem;

            .bar {
              display: inline-block;
              position: relative;
              margin-right: 1px;
              width: 3px;
              height: 1px;
              overflow: hidden;
              background-color: #fd3912;
              color: transparent;
              animation-name: pulse;
              animation-duration: 1s;
              animation-iteration-count: infinite;
              border-radius: 25%;

              &1 {
                animation-delay: 0.5s;
              }

              &3 {
                animation-delay: 1.2s;
              }
            }
          }
        }

        .scrolling-title {
          display: flex;
          overflow: hidden;
          max-width: 150px;
          white-space: nowrap;

          .title {
            font-size: 1.4rem;
            font-weight: bold;
            animation: scroll 40s linear infinite;

            span {
              margin-right: 4rem;
            }
          }

          div {
            animation: scroll 10s linear infinite;
          }

          @keyframes scroll {
            from {
              transform: translate3d(0, 0, 0);
            }

            to {
              transform: translate3d(-100%, 0, 0);
            }
          }
        }

        .description {
          font-size: 1.5rem;
          color: #ffffffcc;
        }
      }

      .album {
        position: absolute;
        right: 0;
        top: 50%;
        transform: translateY(-50%);
        max-width: 30%;
        overflow: hidden;
      }
    }

    &.hover .title {
      color: #fd3912;
    }
  }

  @keyframes pulse {
    0% {
      height: 1px;
      margin-top: 0;
    }

    10% {
      height: 15px;
      margin-top: -15px;
    }

    50% {
      height: 5px;
      margin-top: -5px;
    }

    60% {
      height: 7px;
      margin-top: -7x;
    }

    80% {
      height: 15px;
      margin-top: -15px;
    }

    100% {
      height: 1px;
      margin-top: 0;
    }
  }
</style>

This component mirrors the structure used on the Home page, omitting specific icons and styling elements such as media queries. However, these can be effortlessly incorporated as needed.

Building the Perfect Spotify Now Playing Widget in SvelteKit

Creating Spotify App

Storing sensitive key in an .env file

Spotify Authorization Code Flow

Requesting User Authorization

Getting a Refresh Token

Getting an Access Token

Use the obtained access token to request to Spotify API

Now Playing / Last Played Endpoint

Top Tracks Endpoint

Creating Spotify Component

Comments

Related Articles

Building a High-Performance Portfolio with SvelteKit: A Deep Dive

SvelteKit, Docker, and Umami: A Winning Combination for Web Analytics

#Creating Spotify App

#Storing sensitive key in an .env file

#Spotify Authorization Code Flow

#Requesting User Authorization

#Getting a Refresh Token

#Getting an Access Token

#Use the obtained access token to request to Spotify API

#Now Playing / Last Played Endpoint

#Top Tracks Endpoint

#Creating Spotify Component

Comments

Related Articles

Building a High-Performance Portfolio with SvelteKit: A Deep Dive

SvelteKit, Docker, and Umami: A Winning Combination for Web Analytics

Creating Spotify App

Storing sensitive key in an .env file

Spotify Authorization Code Flow

Requesting User Authorization

Getting a Refresh Token

Getting an Access Token

Use the obtained access token to request to Spotify API

Now Playing / Last Played Endpoint

Top Tracks Endpoint

Creating Spotify Component
